Orange Pi i96
Electra Store
SKU: DB-25899
1,200.00 EGP
In Stock
0 available
1
Categories: Orange Pi
Overview
<span style="font-size: medium;background-color: #ffffff;color: #000000"><strong>The Orange Pi i96</strong> is an open-source single-board computer built upon the 96Boards IoT Edition specification. It can run Android 4.4, Ubuntu, Debian, Raspbian and more. Based on the RDA8810PL ARM Cortex-A5 32bit SoC.</span>
Description
The Orange Pi i96 is for anyone who wants to start creating with open source technology – not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you.
You can buid:
- A computer
- Wireless servers
- Games and consoles
- Music and sounds
- HD video showcases
- Audio Systems
- Android Applications
- Scratch demos
- And more...
Features and User Manual:
Component Description
SoC RDA8810PL ARM Cortex-A5 32bit
Memory Integrated 256MB LPDDR2 SDRAM
CPU ARM Cortex-A5 32bit
Memory Integrated 256MB LPDDR2 SDRAM
CPU ARM Cortex-A5 32bit
GPU Vivante GC860 3D GPU
RAM Integrated 256MB LPDDR2 SDRAM
Storage TF card / Integrated 500MB 8Bit 1.8V 4K SLC Nand Flash
Wireless RDA5991, WIFI BT
Wireless RDA5991, WIFI BT
USB One USB 2.0 HOST, One USB 2.0 OTG
Camera MIPI CSI-2 Connector for camera sensor up to 2MP
Expansion 40 Pins Header
LED Power led
Button Power Button(SW602)
Power USB OTG input can supply power / Battery input can supply power(Optional)
OS Support Android, Ubuntu, Debian, etc.
Size 60mm × 30mm
