Orange Pi R1

685,00 EGP

Out of stock

Orange Pi R1 is for anyone who wants to start creating with technology – not just consuming it. It’s a simple, fun, useful tool that you can use to start taking control of the world around you.

Compare
SKU: DB-25929 Category: Tags: ,
Orange Pi R1 is for anyone who wants to start creating with technology – not just consuming it. It’s a simple, fun, useful tool that you can use to start taking control of the world around you.
You can buid:

  • A computer
  • A wireless server
  • Games
  • Music and sounds
  • HD video
  • A speaker
  • Android
  • Scratch
  • Pretty much anything else, because Orange Pi Prime is open source

Specification

Component              Description

Memory                     256MB DDR3 (shared with GPU)


CPU                          H2 Quad-core 32-bit Cortex-A7


GPU                          Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0

Onboard Storage     TF card (Max. 32GB) / Spi flash(16MB)


Onboard Network     100M/10M Ethernet RJ45(Onboard Ethernet)

                                     100M/10M Ethernet RJ45(RTL8152B)


Onboard WIFI          Realtek RTL8189FTV, IEEE 802.11 b/g/n


Video Outputs          Supports external board via 13pins


Audio Input               No


Power Source          USB OTG can supply power


GPIO(1×3) pin         UART, ground.


Low-level
peripherals              26 Pins Header, compatible with Raspberry Pi B+

                                 13 Pins Header, with 2x USB, IR pin, AUDIO(MIC, AV)

OS Support             Android4.4, Lubuntu, Debian, Armbian Image


LED                         Power led & Status led


Buttons                  Power Button(SW602)


Size                         45 mm × 60mm


Weight                    35g

Be the first to review “Orange Pi R1”

Reviews

There are no reviews yet.
