Orange Pi Zero Plus
Electra Store
SKU: DB-25934
825.00 EGP
Out of Stock
Categories: Orange Pi
Overview
<p><span style="font-size: medium; color: #000000;">Orange Pi Zero Plus is for anyone who wants to start creating with technology – not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you.</span></p>
Description
Orange Pi Zero Plus is for anyone who wants to start creating with technology – not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you.
You can buid:
- A computer
- A wireless server
- Games
- Music and sounds
- HD video
- A speaker
- Android
- Scratch
- Pretty much anything else, because Orange Pi Prime is open source
Specification
Component Description
Memory 512MB DDR3 (shared with GPU)
CPU H5 Quad-core 64-bit Cortex-A53
GPU Hexa-core Mali450 OpenGL ES 2.0/1.1/1.0
OpenVG 1.1
EGL 40 GFlops
Pixel fill rate greater than 2.7GPixel/s
OpenVG 1.1
EGL 40 GFlops
Pixel fill rate greater than 2.7GPixel/s
Onboard Storage TF card (Max. 32GB) / Spi flash(2MB)
Wifi Antenne Yes Onboard Network 1000M/100M/10M Ethernet RJ45
Onboard WIFI Realtek RTL8189FTV, IEEE 802.11 b/g/n Video Outputs Supports external board via 13pins
Audio Input No
Power Source USB OTG can supply power
USB 2.0 Ports One USB 2.0 HOST, One USB 2.0 OTG
GPIO(1x3) pin UART, ground.
Low-level
peripherals 26 Pins Header, compatible with Raspberry Pi B
13 Pins Header, with 2x USB, IR pin, AUDIO(MIC, AV)
13 Pins Header, with 2x USB, IR pin, AUDIO(MIC, AV)
OS Support Android5.1, Lubuntu, Debian, Armbian Image
LED Power led & Status led
Buttons Power Button(SW602) Size 45 mm × 48mm
Weight 26g
