TL431 Programmable Precision References

The TL431 programmable precision references are three-terminal adjustable shunt regulators. They offer excellent temperature stability. Use them in power supplies and voltage monitoring. This 3-pack provides reliable performance for your projects.

These devices act as a precision voltage reference. You can set the output voltage with two external resistors. The TL431 operates from 2.5V to 36V. It delivers up to 100mA of sink current. This makes it versatile for many applications.

The TL431 programmable precision references work as a stable voltage clamp. They compare an internal reference to a feedback voltage. This feedback loop keeps the output very accurate. The device sinks current to maintain the set voltage. It responds quickly to changes in load or input. This makes it ideal for regulated power supplies. You can also use it as a low-cost voltage detector. The TL431 programmable precision references replace older zener diodes. They offer much better precision and stability. The wide voltage range covers many common needs. You can set any voltage between 2.5V and 36V. Two external resistors are all you need. This flexibility saves design time and cost.

Key Features

• Adjustable output voltage from 2.5V to 36V with two resistors
• Low dynamic output impedance of 0.2 ohms typical
• 1% initial voltage tolerance for accurate regulation
• Wide operating current range from 1mA to 100mA
• Temperature compensated for stable performance over -40°C to +125°C
• Available in TO-92 package for easy breadboard use

What's Included

• Three TL431 programmable precision references in TO-92 package
• Each device is individually tested for performance
• Comes in a static-safe bag for protection
• Includes a quick reference card with pinout diagram

Use Cases

Engineers and hobbyists use the TL431 in linear power supplies. It works well in battery chargers and voltage monitors. You can also use it as a precision comparator. This IC is a staple in analog circuit design.

Typical buyers include electronics students and makers. They build custom power supplies for their projects. Repair technicians also use these references. They fix old equipment with faulty voltage regulators. The TL431 programmable precision references are popular in audio circuits too. They provide a clean bias voltage for amplifiers. Industrial designers use them in sensor interfaces. The stable reference improves measurement accuracy. Even robotics enthusiasts rely on them. They ensure consistent voltage for motors and controllers. This part is essential for any voltage regulation task.

Upgrade your projects with these TL431 programmable precision references. They ensure stable and accurate voltage regulation. Order now from Electra Store for fast shipping. Your next design will benefit from this reliable component. Don't wait to get your hands on this versatile part. Click add to cart today. We ship within 24 hours. You will have your TL431 programmable precision references soon. Start building better circuits right away.
