Orange Pi PC

825.00 EGP

Out of stock

It’s an open-source single-board computer. It can run Android 4.4, Ubuntu, Debian, Raspbian Image, as well as the banana pi Image. It uses the AllWinner H3 SoC, and has 1GB DDR3 SDRAM

Compare
SKU: DB-25917 Category: Tags: ,
Orange Pi PC is for anyone who wants to start creating with technology – not just consuming it. It’s a simple, fun, useful tool that you can use to start taking control of the world around you.
Features and User Manual:



Component              Description

Memory                    1GB DDR3 (shared with GPU)


CPU                          H3 Quad-core Cortex-A7 H.265/HEVC 4K




GPU                          ·Mali400MP2 GPU @600MHz                                  ·Supports OpenGL ES 2.0







Onboard Storage     TF card (Max. 32GB) / MMC card slot


Onboard Network     10/100M Ethernet RJ45






Video Input                A CSI input connector Camera Supports 8-bit YUV422 CMOS sensor interfaceSupports CCIR656 protocol for NTSC and PALSupports SM pixel camera sensorSupports video capture solution up to 1080p@30fps



Video Outputs          A CSI input connector Camera:Supports 8-bit YUV422 CMOS sensor interfaceSupports CCIR656 protocol for NTSC and PALSupports SM pixel camera sensorSupports video capture solution up to 1080p@30fps






Audio Input               MIC




Power Source          DC input can supply power, but USB OTG input don’t supply power




USB 2.0 Ports           Three USB 2.0 HOST, one USB 2.0 OTG




GPIO(1×3) pin          UART, ground.




Low-level
peripherals              40 Pins Header,compatible with Raspberry Pi B+



OS Support             Android Ubuntu, Debian, Raspbian Image.




LED                         Power led & Status led




Key                          IR input, POWER




Size                         85 mm × 55mm




Weight                    38g
