Digital Logic Circuit Kit – Pharos University in Alexandria 2026–2027

Product Description

This digital logic circuit kit for Pharos University in Alexandria students is a complete bench set for building and testing logic circuits on a breadboard during the 2026–2027 academic year. It brings together the logic ICs, input switches, indicator LEDs, display, power parts, and basic tools a student needs, so there is no need to piece the list together from different sources.

The core of the kit is a set of 74-series ICs. The 7404 hex inverter, 7408 quad AND gate, 7432 quad OR gate, and 7486 quad XOR gate cover the fundamental gate functions. The 7483 4-bit binary full adder and the 7485 4-bit magnitude comparator extend the kit into arithmetic and comparison circuits, while the 7447 BCD to 7-segment decoder/driver works with the 5161BS common anode displays to turn a binary value into a readable digit.

Working with the kit follows a simple pattern. DIP switches and push buttons act as inputs, letting you set each line to a logic high or low by hand. The ICs process those signals, and the 5mm LEDs or the 7-segment displays show the result. This makes it easy to confirm a truth table, trace how a signal moves through a gate network, or check that an adder produces the right sum. A 5V 2A wall adapter supplies power to the circuits, and the kit also includes a 7805 5V positive regulator and a DC female wire connector for anyone who wants to build their own regulated 5V stage.

The quantities are generous for a student kit. With 24 LEDs, 12 resistors of 330 Ohm for current limiting, two 8-way DIP switches, six 4-way DIP switches, and eight push buttons, multi-bit circuits such as a 4-bit adder or comparator can be wired without running short of inputs or indicators. Several of each logic IC are included, so you can combine gates into larger designs. A 840-point breadboard with split power rails gives enough room for the layout, and the 140-piece jumper wire kit and a wire cutter cover the wiring and trimming.

Typical buyers are students preparing lab work and assignments, and anyone practicing combinational logic at home who wants a parts set that matches the course list instead of guessing at substitutes. Everything arrives in one package, which also helps when several students need identical sets.

Features

• Gate ICs covering NOT, AND, OR, and XOR functions for building and verifying logic circuits

• Adder and magnitude comparator ICs for arithmetic and comparison experiments

• BCD decoder/driver paired with common anode displays for numeric output

• Large LED set for showing the state of several lines at once

• Mix of DIP switches and push buttons for fixed and momentary inputs

• Regulator and DC connector included for building a 5V supply stage

• Jumper wire kit and wire cutter supplied for wiring and trimming

• Spare IC quantities allow larger multi-gate designs

• Single package that matches the course component list

Specifications

• Breadboard: 840 points, split power rails

• Wall Power Adapter: 5V DC, 2A

• Voltage Regulator: 7805, positive, 5V

• Logic ICs (DIP): 7404 hex inverter, 7408 quad 2-input AND, 7432 quad 2-input OR, 7486 quad 2-input XOR

• Arithmetic ICs (DIP): 7483 4-bit binary full adder, 7485 4-bit magnitude comparator

• Display Driver (DIP): 7447 BCD to 7-segment decoder/driver, 15V open-collector outputs

• 7-Segment Display: 5161BS, common anode

• LEDs: 5mm, round, assorted colors

• Resistors: 330 Ohm, 1K Ohm, 100K Ohm, 1/4 Watt, 5%

• DIP Switches: 8-way and 4-way

• Push Buttons: 6x6x6 mm tack switch, standard type

• Terminal Block: 2-pin, PCB mount, screw type, 5mm pitch, green

• Jumper Wire Kit: 140 pieces

• Wire Cutter: Model 170

Applications

• Building and verifying logic gate circuits and truth tables

• 4-bit binary addition circuits

• 4-bit magnitude comparison circuits

• BCD to 7-segment display circuits

• Combining gates into larger combinational logic designs

• University digital logic lab work and assignments

• Breadboard prototyping and self-study of digital design

• Wiring and testing small 5V logic projects

Package Includes

• 1x Breadboard 840 Point (Split Power Rails)

• 1x Wall Power Adapter 5Vdc 2A

• 1x 12V DC Power Adapter Female Wire Connector

• 1x 140 pcs Breadboard Jumper Wire Kit

• 1x Wire Cutter Model 170

• 2x DIP Switch 8 Way

• 6x DIP Switch 4 Way

• 8x Push Button (6x6x6 mm Tack Switch, Standard Type)

• 24x 5mm LED Lights, Round, All Colors

• 12x Resistor 330 Ohm 1/4 Watt 5%

• 5x Resistor 1K Ohm 1/4 Watt 5%

• 5x Resistor 100K Ohm 1/4 Watt 5%

• 4x 7-Segment Common Anode 5161BS

• 4x 7404 DIP Hex Inverter Logic NOT Gate

• 4x 7408 DIP Quad 2-Input Logic AND Gate

• 4x 7432 DIP Quad 2-Input Logic OR Gate

• 2x 7447 DIP BCD to 7-Segment Decoder / Driver

• 2x 7483 DIP 4-Bit Binary Full Adder

• 2x 7485 DIP 4-Bit Magnitude Comparator

• 4x 7486 DIP Quad 2-Input Logic XOR Gate

• 1x 7805 Positive Voltage Regulator 5V

• 1x 2 Pin PCB Mount Screw Terminal Block, 5mm Pitch, Green
