UT343D Coating Thickness Gauge

UT343D coating thickness gauge can measure coating thickness on ferrous and non-ferrous materials. This device is designed with a unique quick test feature, which allows users to set thickness range and using a 3-color LED and audio alarm to quickly determine if coating being tested falls within the preset range, greatly increasing work efficiency.

UT343 display is auto rotatable. This CE certified device can store up to 500 sets of data for further analysis through the PC analytical software that is included.
SKU: TL-28560 Categories: , , , Tags: ,

$ 272.00 $ 272.00

Available on backorder

Compare

Product Description

  • UT343D coating thickness gauge can measure coating thickness on ferrous and non-ferrous materials.
  • This device is designed with a unique quick test feature, which allows users to set thickness range and using a 3-color LED and audio alarm to quickly determine if coating being tested falls within the preset range, greatly increasing work efficiency.
  • UT343 display is auto rotatable.
  • This CE-certified device can store up to 500 sets of data for further analysis through the PC analytical software that is included.
Applications:
  • It is widely used in manufacturing
  • Metal processing
  • Aerospace
  • Marine mechanics
  • Rail transport
  • Scientific research
  • Quality supervision, and other industries.

UT343D-English-Manual

Package Included:

  • 1 X UT343D Coating Thickness Gauge
Specifications Range
Measuring range 0~1250um
Accuracy ±(3%H+1)um
Resolution 0.1um (0~99.9um); 1um (100~1250um)
Measurement method Single/Continuous
Measurement mode Max/Min/Avg
Metal type Ferrous/ non-ferrous
Features
Display type 2.0-inches TFT LCD (320 x 240 pixels)
LCD brightness control
Auto rotatable screen
Unit conversion
Audio alarm
LED alarm
PC analysis software
USB communication
Quick test mode
Data storage  500 groups
Auto power off
Low battery indication
General Characteristics
Power 1.5V AA battery (LR6) x 2
Display 48mm x 36mm
Product color Red and grey
Product net weight 175g
Product size 153.5mm x 64.5mm x 41mm
Standard accessories Micro USB interface cable, standard piece, batteries, cloth bag
Weight 0.175 kg
Dimensions 15.35 × 6.45 × 4.1 cm
