Key Features:

✔ Dual H-Bridge Design – Independently control 2 DC motors (or 1 stepper motor) in forward, reverse, or PWM speed modes. ✔ High Current Capacity – 2A continuous per channel (3A peak) – ideal for large motors (12V–24V). ✔ Arduino Shield Form Factor – Stacks directly onto Uno, Mega, and other 5V/3.3V boards (no wiring needed). ✔ Wide Voltage Range (5V–35V) – Supports 6V, 12V, and 24V motor power. ✔ Built-in Protection – Heat sink + diode protection against back-EMF. ✔ Easy Control – Uses Arduino PWM pins for speed regulation.

Applications:

• Robotics – Drive wheels, arms, or tracked vehicles.

• CNC & 3D Printers – Control stepper motors for precise movement.

• Industrial Automation – Conveyor belts, actuator control.

• DIY RC Cars/Boats – High-torque motor control.

Technical Specifications:

• Motor Voltage: 5V–35V DC.

• Logic Voltage: 5V (from Arduino or external supply).

• Max Current: 2A per channel (3A peak, with heat sink).

• Control Interface: PWM (speed) + digital (direction).

• Compatible Motors: Brushed DC, stepper (bipolar/unipolar).

Pinout & Connections:

• Motor A/B Outputs – Connect to two DC motors (or stepper coils).

• Power Input – Vin (6V–35V) + GND (separate from Arduino power).

• Control Pins (Default Arduino mapping):

  • ENA/ENB – PWM speed control (D5/D6).

  • IN1/IN2 (Motor A) – Direction (D7/D8).

  • IN3/IN4 (Motor B) – Direction (D9/D10).

Package Includes:

• 1x L298 Motor Driver Shield.

Why Choose the L298 Shield?

✅ No Extra Wiring – Plug directly onto Arduino. ✅ Proven Reliability – Industrial-grade H-bridge design. ✅ Stepper Motor Support – Drives 4-wire or 6-wire steppers.
