3M660-N Microstep Driver
Electra Store
SKU: MD-27871
990.00 EGP
In Stock
1
Categories: Motor Drivers
Description
Microstep Driver
Description- 3M660 is a constant torque microstepping driver, voltage range from 24-58VDC, it’s suitable for various 3-phase NEMA23 & NEMA34 hybrid stepper motor.
- With the build-in constant current chopping circuit similar to servo driver, the motor run stable without vibration and noise in low speed.
- The torque in high speed is far better than traditional 3-phase and 5-phase stepper motor because of the high voltage.
- The precision can be high to 12800 steps/rev.
Specifications
- Peak Output Current: 1.35 - 5.8 Amps
- Supply Voltage: 24-58 VDC
- Logic Signal Current: 10mA
- Pulse Input Frequency: 0 - 200 Khz
- Pulse Low Level Time: 2.5ms
Environment
- Space: Avoid dust, oil fog & corrosive gases
- Storage Temperature: 10∩ - 80∩
- Working Temperature: 65∩ Max
- Humidity: <80%RH
- Vibration: 5.9m/s Max
