UT15B PRO 1000V True RMS Digital Multimeter
Roll over image to zoom in
Features of UT15B PRO 1000V True RMS Digital Multimeters
- VFC
- Auto range
- Relative mode
- Flashlight
- True RMS
- Continuity test
- Diode test
- Max/Min
- Data hold
- Low battery indication
- Auto backlight
- Auto power off
Specifications of UT15B PRO 1000V True RMS Digital Multimeters
| Specifications | Range | UT15B PRO |
| Certifications | CE/RoHS/cETLus | |
| Safety ratings | CAT III 1000V/CAT IV 600V | |
| DC voltage (V) | 1000V | ±(0.5%+3) |
| AC voltage (V) | 1000V | ±(1%+3) |
| AC current (A) | 10A | ±(1%+3) |
| DC current (A) | 10A | ±(0.8%+3) |
| Resistance (Ω) | 60MΩ | ±(0.5%+2) |
| Capacitance (F) | 6000μF | ±(2%+5) |
| Display count | 6000 | |
| AC frequency response | 40~500Hz | |
| General Characteristics | ||
| Power | 1.5V battery (LR6) x 2 | |
| Product net weight | UT17B PRO: 484g | |
| Product size | 195mm x 95mm x 58mm | |
