UNI-T UTP3305II DC Power Supply 3 Channel
Electra Store
SKU: UT-3305
11,250.00 EGP
11,250.00 EGP
Save 0%
In Stock
1
Categories: Measuring Devices, UNI-T
Description
Uni-T UTP3305II DC Power Supply
The UNI-T UTP3305-II is a linear high-performance, yet affordable lab power supply that features two fully adjustable channels and one fixed channel. The adjustable channels can provide 160W of power each, over the range of 0-32V and 0-5A. The third channel provides a fixed output of 5V and 3A. Internally, the adjustable channels can be connected in series or parallel, delivering respectively a maximum voltage of 64V or a maximum current of 10A. The UNI-T UTP3303-II power supply is an alternative power supply from the same series.
A disadvantage is that the power supply only has a 'coarse' adjustment knob, making it more difficult to set the power supply precisely. Also, the 3rd channel is fixed, which means that it is not possible to set a different voltage, for example 3.3V. The power supply also has one button to switch all channels on or off simultaneously, which makes it impossible to switch individual channels on or off.
- 3 Channels.
- Output Voltage: 0~32V, 5V.
- Output Current: 0~5A.
- Load Regulation: – Voltage: ≤0.01% 3mV. – Current: ≤0.2% 3mA.
- Line Regulation – Voltage: ≤0.01% 3mV. – Current: ≤0.1% 5mA.
- Ripple and Noise – Voltage: 1mVrms. – Current: 3mArms.
- Display Accuracy: ≤±1%rdg 2digits.
- Reliability (MTBF): ≥2000 hours.
- Display: LED shows Voltage and Current values.
- Power: Input Voltage: 115VAC/230VAC (Optional); Frequency: 50/60Hz.
- Weight: 10kg
- Size: 260x176x317mm.
- Standard Accessories: Power Cord.
