UNI-T UTP1306 DC Power Supply

UNI-T UTP1306 DC Power Supply

✅ Key Features:

• Output Voltage: 0–32V

• Output Current: 0–6A

• Output Power: 192W

• Display: 4-digit LED for voltage and current

• Resolution: Voltage: 10 mV; Current: 1 mA

• Protection Functions: Over Voltage Protection (OVP), Over Current Protection (OCP), Over Temperature Protection (OTP)

• Memory Storage: 3 groups of preset voltage and current settings for quick recall

• Independent Output Switch: Allows for safe and controlled power delivery

• Cooling System: Temperature-controlled fan for efficient heat dissipation

• Low Ripple and Noise: Ensures clean and stable output

Technical Specifications:

• Load Regulation:

  • Voltage (CV): <0.1% + 5 mV

  • Current (CC): <0.2% + 3 mA

• Line Regulation:

  • Voltage (CV): <0.01% + 5 mV

  • Current (CC): <0.2% + 3 mA

• Ripple and Noise:

  • Voltage: ≤10 mVrms

  • Current: ≤5 mArms

• Accuracy (at 25°C ±5°C):

  • Voltage: <0.1% + 5 mV

  • Current: <0.2% + 3 mA

• Input Voltage: 110V/220V AC ±10%, 50Hz–60Hz

• Operating Temperature: 0°C to 40°C, <80% RH

• Storage Temperature: -15°C to 70°C, <80% RH

• Dimensions: 80 mm × 150 mm × 230 mm

• Weight: Approximately 1.9 kg

🛠️ Applications:

• Electronics Design & Testing: Provides stable power for circuit development and analysis.

• Educational Laboratories: Ideal for teaching power supply principles and hands-on experiments.

• Maintenance & Repair: Suitable for servicing electronic devices requiring precise voltage and current.

• Research & Development: Supports various R&D projects needing reliable power sources.
