UNI-T UT202T Smart AC Clamp Meters

Name: UNI-T UT202T Smart AC Clamp Meters
Brand: Electra Store
SKU: UT-20021
Price: 1150.00 EGP
Availability: OutOfStock

Electra Store SKU: UT-20021

1,150.00 EGP

Available on Backorder

Quantity

Share to

Categories: Measuring Devices, UNI-T

Description

UNI-T UT202T Smart AC Clamp Meters

Features

Certificates: CE, UKCA, cETLus● Button-design clamp meter.● One-hand operation and easy to use.● True RMS / 9999 counts.● Jaw opening: 28mm.● 600V AC/DC voltage measurement.● 600A AC current measurement.● Dual display: V HZ and A HZ.● Bright backlight / Flashlight.● Non-contact voltage (NCV).● CAT III 600V.

Specifications

Specifications	Range	UT202T	UT202BT
Certificates	CE/UKCA/cETLus
DC voltage (V)	600V	±(0.5%＋3)	±(0.5%＋3)
AC voltage (V)	600V	±(0.8%＋3)	±(0.8%＋3)
AC current (A)	600A	±(2.5% 5)	±(2.5% 5)
Resistance (Ω)	6MΩ	±(0.8% 3)
Resistance (Ω)	100MΩ		±(0.8% 3)
Frequency (Hz)	40Hz~1000Hz	±(1.0％ 5)	±(1.0％ 5)
Capacitance (F)	100mF	±(4% 5)	±(4% 5)
Temperature (℃/℉)	-40℃~1000℃/-40℉~1832℉		±5/±9
Features
Jaw opening		28mm	28mm
Display count		9999	9999
Dual display		√	√
Auto range		√	√
NCV		√	√
Continuity		√	√
PEAK hold			√
Low pass filter			√
Inrush current			√
Audible visual indication		√	√
Low battery indication	＜2.4V approximately	√	√
Data hold		√	√
Auto power off	Approximately 15 minutes	√	√
Flashlight		√	√
Bluetooth			√
Safety rating	CAT Ⅲ 600V
General Characteristics
Power	AAA 1.5V x 2
Product color	Red Gray
Product net weight	UT202T: 241g (Including batteries); UT202BT: 251g (Including batteries)
Product size	201.5 x 47 x 28mm
Standard accessories	UT202T: Test leads, batteries; UT202BT: Test leads, batteries, temperature probe
Standard individual packing	Gift box, carrying bag, English manual
Standard quantity per carton	40 pcs
Standard carton measurement	485×295×385mm
