HX711 Weighing Scale Analog to Digital Converter 24 bit
Electra Store
SKU: MD-26811
55.00 EGP
In Stock
1
Categories: Converters
Description
- Differential input voltage :Ā Ā±40mV ( Full-scale differential input voltage is Ā± 40mV )
- Data accuracy :Ā 24 bit (Ā A/D converter chipĀ )
- Refresh frequency:Ā 80 Hz
- Operating Voltage :Ā 5V DC (2.6V ~ 5.5V)
- Operating current :Ā <10 mA
- Operation supply voltage range:Ā 2.7V ~ 5.5V
- Operation temperature range:Ā -40 ~ 85ā
- Size :Ā 33mm x 20mm
- Two selectable differential input channels
- On-chip active low noise PGA with selectable gain of 32, 64 and 128
- On-chip power supply regulator for load-cell and ADC analog power supply
- On-chip oscillator requiring no external component with optional external crystal
- On-chip power-on-reset
- Simple digital control and serial interface: pin-driven controls, no programming needed
- Measurement Resolution:Ā 24 bit
- Selectable 10SPS or 80SPS output data rate
- Simultaneous 50 and 60Hz supply rejection
- 1 x HX711 Weighing Scale Analog to Digital Converter 24 bit
