7" Color TFT LCD Module MCU 800x480 LMT070DICFWD-NJA

7″ Color TFT LCD Module MCU 800×480 – LMT070DICFWD-NJA

1,700.00 EGP

– resolution: 800×480
– Interface: MCUVoltage: 5V
– Temperature: -20°C ~ 70°C
– Outline: 190.0mm x 112.0mm x 13.3mm
– Size: 7″inc
– Active Area: 154.08mm x 85.92mm
– Touch Screen: RTP
Category: Tags: , ,

Description

7″ Color TFT LCD Module MCU 800×480 – LMT070DICFWD-NJA

General Specification

Screen Size(Diagonal) :7.0”
Outline Dimension : 190.0 x 112.0x 13.3max (mm) see attached drawing for details
Active Area : 154.08 x 85.92 (mm) Color Depth: 65k
Number of dots : 800 x 480
Pixel Pitch : 0.0642 x0.179 (mm)
Pixel Configuration : RGB Stripe
Backlight : LED
Surface Treatment : Anti-Glare Treatment
Viewing Direction : 6H (gray scale inverse) (*2) 12H(*3)
Operating Temperature : -20 ~ 70°C
Storage Temperature : -30 ~ 80°C

LMT070DICFWD-NJALCD Module User Manual download
