Description
Uni-T Ut692g Handheld Optical Power Meter/Optical Multimeter (Power Meter & VFL)
Product Description
general information:
- Type: Fiber Optic Tester.
- Model NO.: UT692G.
- Certification: CE, RoHS.
- Measurement Range: -50~ 26dBm.
- Wavelength Range: 800nm ~ 1700nm.
- Detector Type: Ingaas.
- Uncertainty: ±5%.
- Display Resolution: Linear: 0.1%, Logarithmic: 0.01dBm.
- Connector: FC (Optional: Sc/St).
- Trademark: UNI-T.
- Specification: 189mm × 87mm × 45mm.
- Origin: Dongguan, China.
- 2.4in large LCD screen with clearly digital readout, backlight and flashlight for easy operation in darkness.
- Support linear mW and non-linear dBm simultaneous display.IP65 dust and water proof, can be used indoors and outdoors.
- Low battery indication and 10 minutes auto power to save energy.With wavelength memory function, user self-calibration function.
- 8 kinds of calibrated wavelength can be selected and simultaneously display on the LCD.
- Apply in the construction and maintenance of optical cable, judge the performance of optical device, optical fiber communications, etc.
The UT692G handheld optical power meter is used to measure absolute optical power or relative loss of optical power through length of fiber optic wires. UT692G is designed to be durable that the meter can withstand 2m drop and have a dust/water resistance rating of IP65. In addition, UT692G's other features include backlight display, flashlight, auto power off, wavelength storage/recall, user calibration, and ultra-wide optical power test range.
Features of UT692G Optical Power Meter
- Low battery indication.
- Auto power off.
- IP65/2m drop proof.
- Flashlight.
Application of UT692G Optical Power Meter
- Cable construction and maintenance.
- Optical fiber communication.
- Evaluation of optical equipment.
- Production, installation, operation and maintenance of fiber optic transmission systems.
- Optical engineering, production plant or facility maintenance.
Technical Specification of UT692G Optical Power Meter
| Specifications | UT692D | UT692G |
| Measurement Range (dBm) | -70~10 | -50~26 |
| Wavelength Range (nm) | 800-1700 | |
| Connector | Universal connector FC/SC/ST ( FC as standard, SC and ST adapter as options) | |
| Detector Type | InGaAs | |
| Uncertainty | ±5% | |
| Calibrated Wavelength (nm) | 850, 980, 1300, 1310, 1490, 1550, 1625, 1650 | |
| Display Resolution | Linear: 0.1%, logarithmic: 0.01dBm | |
| Auto Power Off (min) | 10 | |
| Power Supply | 1. 5V AA alkaline battery (3 pcs) | |
| Low Battery Indication | Low battery indication at about 3.3V, auto power off at about 3V | |
| Battery Operation Time (h) | ≥60 | |
| Drop Height (M) | 2 | |
| Operating Temperature | 0°C~40°C | |
| Storage Temperature | -10°C~50°C | |
| Dimensions (mm) | 189×87×45 | |
| Net Weight (g) | 286 | |
| Certification | CE, IP65, RoHS | |
| General Characterisitics | ||
| Power | 1.5V battery x 3 | |
| Product color | Red and grey | |
| Product net weight | 286g | |
| Product size | 189mm x 87mm x 45mm | |
| Standard accessories | 1.5V Batteries, English manual, Dedicated pouch | |
| Standard individual packing | gift box | |
| Standard quantity per carton | 10pcs | |
| Standard carton measurement | 295mm x 250mm x 210mm | |
| Standard carton gross weight | 14.5Kg(TBC) | |
