Key Features:

1. High-Performance Signal Generation

• Dual-Channel Output: Independent or synchronized operation with 400 MHz bandwidth per channel.

• 14-Bit Vertical Resolution: Ensures high signal accuracy with minimal distortion.

• 1.2 GSa/s Sampling Rate: Delivers fast, precise waveform reproduction.

• Up to 800 MHz Pulse Wave Output: Ideal for high-speed digital signal simulation.

2. Versatile Waveform Generation

• Standard Waveforms: Sine, square, pulse, ramp, noise, and DC signals.

• Arbitrary Waveforms (ARB): User-defined waveforms with 16 Mpts memory depth for complex signal simulation.

• Modulation & Sweep Modes: Supports AM, FM, PM, FSK, ASK, PWM, and linear/logarithmic sweep.

• Built-in Harmonic & Arbitrary Waveform Editor: Customize signals with ease.

3. Advanced Functionality

• Dual-Channel Phase Control: Adjust phase difference between channels for synchronized applications.

• High-Stability Clock Source: Low jitter and high frequency accuracy (±1 ppm).

• Burst Mode & Triggering: Supports N-cycle burst, gate control, and external triggering.

• IQ Modulation (Optional): For RF and communication testing.

4. User-Friendly Interface

• 4.3-inch TFT LCD Display: Clear visualization of waveform parameters.

• Intuitive Front-Panel Controls & Knob: Quick adjustments for frequency, amplitude, and offset.

• USB & LAN Connectivity: Remote control via SCPI commands (USB-TMC, LXI-Core compliant).

• Waveform Import/Export: Supports .CSV, .BIN, and .TXT file formats.

5. Robust Design & Portability

• Compact & Lightweight: Easy to integrate into lab or field environments.

• Low Noise & High Stability: Optimized for precision measurements.

• Fanless Cooling System: Silent operation for noise-sensitive applications.

Applications:

✔ Communications Testing (RF, baseband, modulation analysis) ✔ Embedded System Debugging (MCU, FPGA, DSP signal simulation) ✔ Automotive & Aerospace Electronics (Sensor simulation, PWM testing) ✔ Education & Research Labs (Physics, engineering experiments) ✔ Power Electronics & Component Testing (Filters, amplifiers, oscillators)

Technical Specifications:

Package Includes:

• UTG4122A Waveform Generator

• Power Cable

• USB Cable

• Quick Start Guide

• Optional Accessories: BNC cables, remote control software

Why Choose the UNI-T UTG4122A?

✅ High-speed, high-resolution signal generation for demanding applications. ✅ Dual-channel flexibility with precise synchronization. ✅ Extensive modulation & arbitrary waveform support. ✅ User-friendly interface with PC connectivity. ✅ Reliable performance from a trusted test & measurement brand.

Ideal for R&D labs, manufacturing, and education, the UTG4122A provides professional-grade signal generation at an exceptional value.

Order yours today and enhance your testing capabilities with precision and versatility!
