IRF1010E – N-Channel Power MOSFET – TO-220
In Stock
Categories: Transistors
Description
Key Features:
⚡ High Current Handling
-
Continuous Drain Current up to 84A (at 25°C)
-
Pulsed Drain Current: up to 320A
🔋 Low R<sub>DS(on)</sub>
-
On-resistance as low as 0.010Ω, improving efficiency and minimizing heat generation
📐 Fast Switching Speed
-
Ideal for high-speed circuits and switching power supplies
🧱 Standard TO-220 Package
-
Easy to mount with good thermal performance
-
Suitable for heatsink installation
📊 Specifications:
| Parameter | Value |
|---|---|
| Type | N-Channel MOSFET |
| Package | TO-220 |
| V<sub>DS</sub> (Drain-Source Voltage) | 55V |
| I<sub>D</sub> (Continuous Drain Current) | 84A (at 25°C) |
| R<sub>DS(on)</sub> (Max) | 0.010Ω (at V<sub>GS</sub>=10V) |
| Gate Threshold Voltage (V<sub>GS(th)</sub>) | 2.0 – 4.0V |
| Total Gate Charge | ~140nC |
| Max Power Dissipation | 200W |
Applications:
-
DC motor drivers
-
Power switching circuits
-
Inverters and UPS systems
-
DC-DC converters
-
High-efficiency load switching
Note:
For optimal performance, proper heatsinking is recommended during high current operation.
