FS5113R Servo Motor 360° Continuous 14 kg.cm Metal Gears
In Stock
Categories: Motors, Servo Motors
Description
Key Features:
✔ 360° Continuous Rotation – No angle limits (unlike standard 180° servos). ✔ High Torque (14 kg.cm @ 6V) – Handles heavy loads (robotic arms, drivetrains). ✔ Metal Gear Train – Reinforced steel gears for longevity under stress. ✔ Waterproof & Dustproof (IP67) – Works in wet/dirty environments (rain, outdoor robots). ✔ Wide Voltage Range (4.8V–7.2V) – Compatible with 5V Arduino & 6V/7.4V LiPo. ✔ Precision Control – Analog feedback for smooth speed/direction adjustment. ✔ Standard PWM Signal – Works with Arduino, Raspberry Pi, RC controllers.
Applications:
-
Robotics – Wheel drives, conveyor belts, robotic arms.
-
RC Vehicles – Tank treads, boat rudders, crawler steering.
-
Industrial Automation – Small actuators, valve control.
-
DIY Projects – Camera sliders, automated feeders.
Technical Specifications:
-
Operating Voltage: 4.8V–7.2V (6V recommended).
-
Stall Torque:Â 14 kg.cm (6V) / 16 kg.cm (7.2V).
-
Speed: 0.18 sec/60° (6V).
-
Gear Material:Â Steel.
-
Rotation: Continuous 360° (or programmable for limited angles).
-
Connector:Â JR/Futaba standard (3-pin, 22AWG wire).
-
Dimensions:Â 40mm Ă— 20mm Ă— 38mm.
Package Includes:
-
1x FS5113R 360° Continuous Rotation Servo.
-
1x Set of Mounting Hardware (screws/horns).
Why Choose the FS5113R?
✅ No Burnout Risk – Handles stall conditions better than plastic-gear servos. ✅ All-Weather Ready – IP67 sealing resists splashes and dust. ✅ Plug-and-Play – Compatible with most servo controllers.
