UNI-T UT219E Professional Clamp Meters

3,950.00 EGP

UNI-T UT219E is a high-performance True RMS clamp meter engineered for precision electrical measurements in demanding environments. With its 40mm jaw opening and 1000A measurement capacity, this professional-grade tool delivers accurate AC/DC current readings for industrial, commercial, and HVAC applications.

SKU: UT219E Category: UNI-T

Description
Reviews (0)

Description

Key Features & Benefits

✔ True RMS Technology

Measures AC/DC current up to 1000A with ±1.5% accuracy
Correctly measures non-linear loads (VFDs, inverters, LED lighting)

✔ Enhanced Safety Protection

CAT IV 600V/CAT III 1000V safety rating
Double insulation and IP54 protection
Low battery indicator for safe operation

✔ Comprehensive Measurement Capabilities

AC/DC voltage (1000V), resistance (60MΩ), frequency (1kHz)
Capacitance (100mF), diode test, continuity buzzer
Temperature measurement (-40°C to 1000°C with optional probe)

✔ Professional User Experience

Large backlit LCD with analog bar graph
Data Hold & MAX/MIN/AVG recording
Magnetic hanger for hands-free operation
Auto Power Off to conserve battery life

Technical Specifications

Measurement	Range	Accuracy
AC Current	0.1A-1000A	±1.5% + 5 digits
DC Current	0.1A-1000A	±2% + 5 digits
AC/DC Voltage	0.1V-1000V	±0.8% + 3 digits
Resistance	0.1Ω-60MΩ	±0.9% + 2 digits
Frequency	10Hz-1kHz	±1% + 3 digits
Jaw Opening	40mm	–

Professional Applications

Industrial motor current analysis
HVAC system diagnostics
Electrical panel maintenance
Power quality monitoring
Energy efficiency audits

Why Choose UT219E?

✅ Superior Accuracy – True RMS for complex waveforms
✅ Wide Measurement Range – 1000A current capacity
✅ Rugged Construction – Withstands harsh environments
✅ Versatile Functions – Combines multiple test capabilities

Package Includes:
