Description

🔑 Key Features

✔ High-Current Support – 10A bridge rectifier for robust power handling
✔ 4700μF / 35V Capacitor – Reduces ripple for cleaner DC output
✔ Non-Regulated Output – Pure rectified DC (depends on transformer input)
✔ Durable PCB Design – Thick traces for high-current stability
✔ Easy Wiring – Screw terminals for secure connections
✔ Compact & Efficient – Space-saving for DIY projects

---

📊 Technical Specifications

---

🛠 Applications

• High-Power Audio Amplifiers (Class AB, tube amps)

• DC Motor & LED Strip Drivers

• DIY Bench Power Supplies (unregulated stage)

• Battery Chargers (initial rectification stage)

• Industrial Control Circuits



🔌 Wiring Guide

Input (AC Side):

• AC ~ → Connect to transformer secondary (~12V-24V AC)

Output (DC Side):

• + (Positive) → Smoothed DC output

• – (Negative/GND) → Common ground

Optional Upgrades:

• Add a fuse (10A) for overcurrent protection

• Install a heatsink on the rectifier for prolonged high-current use

• Combine with a regulator (LM338, buck converter) for stable voltage

---

⚡ Why Choose This Board?

✅ Handles high current (10A) without overheating
✅ Minimal voltage drop compared to cheap rectifiers
✅ Ready-to-use – No need to assemble from scratch
✅ Affordable for high-power applications

---

📦 Package Includes

• 1 × 4700μF/35V Rectifier Filter Board (10A rated)

• (Pre-soldered bridge rectifier & capacitor)

---

⚠️ Safety Notes

• Do not exceed 35V DC (capacitor limit)

• Ensure proper ventilation for high-current operation

• Check polarity – Reverse connection can damage components

• For 220V AC input, use an isolation transformer
