Description

Description

• Broadcom BCM2837 64bit ARM Cortex-A53 Quad Core Processor SoC running @ 1.2GHz
• 1 GB RAM
• 4 x USB2.0 Ports with up to 1.2A output
• Expanded 40-pin GPIO Header
• Video/Audio Out via 4-pole 3.5mm connector, HDMI, CSI camera, or Raw LCD (DSI)
• Storage: microSD
• 10/100 Ethernet (RJ45)
• BCM43143 WiFi on board
• Bluetooth Low Energy (BLE) on board
• Low-Level Peripherals:
  • 27 x GPIO
  • UART
  • I2C bus
  • SPI bus with two chip selects
  • 3.3V
  • 5V
  • Ground
• Power Requirements: 5V @ 2.4 A via microUSB power source
• Supports Raspbian, Windows 10 IoT Core, OpenELEC, OSMC, Pidora, Arch Linux, RISC OS and More!
• Dimensions: 85mm x 56mm x 17mm
