🖥️ Digital Logic Circuits Lab Kit – Complete Components for Practical Learning

The Digital Logic Circuits (2) – Lab Components Kit is a comprehensive and well-organized set designed for engineering students, electronics hobbyists, and educators. This kit provides everything you need to build, test, and understand digital logic circuits, including counters, shift registers, flip-flops, timers, and display systems.

Perfect for university labs, hands-on coursework, and DIY electronics projects, this kit brings together high-quality capacitors, resistors, ICs, switches, LEDs, and breadboard tools in one complete package.

🔹 Capacitors

A wide selection of electrolytic and ceramic capacitors for timing, filtering, and stabilization in digital circuits:

• 1µF 50V Aluminum Electrolytic Capacitor – 2 pcs

• 10µF 50V Aluminum Electrolytic Capacitor – 2 pcs

• 0.01µF / 10nF Ceramic Capacitor (PF103, 25V) – 2 pcs

• 100nF 50V Ceramic Capacitor – 2 pcs

• 150µF 25V Capacitor – 2 pcs

🔹 Potentiometers

Adjustable resistance control for voltage dividers and testing:

• 1K Ohm Potentiometer – 2 pcs

• 10K Ohm Potentiometer – 2 pcs

• 100K Ohm Potentiometer – 2 pcs

🔹 Resistors

Standard values for current limiting and logic circuit biasing:

• 1K Ohm 1/4 Watt 5% – 5 pcs

• 100K Ohm 1/4 Watt 5% – 5 pcs

🔹 Switches & Inputs

Control and interact with your circuits easily:

• Push button (6x6x6 mm Tact Switch Standard Type) – 4 pcs

• DIP Switch 2 Way – 2 pcs

• DIP Switch 8 Way – 1 pc

🔹 Indicators

Monitor outputs and display results with visual clarity:

• 7-Segment Display (5161BS, Common Anode) – 2 pcs

• 5mm LEDs (All colors) – 5 pcs

🔹 Integrated Circuits (ICs)

A complete set of essential logic ICs, timers, counters, and shift registers for learning digital electronics:

• NE555 / LM555 Timer IC – DIP-8 Precision Timer – 2 pcs

• 7447 DIP BCD To 7-Segment Decoder / Driver – 2 pcs

• 74190 DIP Synchronous Up/Down Decade Counter – 2 pcs

• 74195 DIP 4-Bit Parallel-Access Shift Register – 2 pcs

• 74163 DIP Synchronous 4-Bit Binary Counter – 2 pcs

• 74112 DIP Dual J-K Negative-Edge-Triggered Flip-Flop – 2 pcs

• 7404 DIP Hex Inverter (NOT Gate) – 2 pcs

• 7408 DIP Quad 2-Input AND Gate – 2 pcs

• 7432 DIP Quad 2-Input OR Gate – 2 pcs

This collection allows you to design and practice combinational logic, sequential circuits, counters, registers, and timing-based applications.

🔹 Prototyping Tools

Everything needed for clean and reliable circuit assembly:

• Breadboard 840 Points (Splitted Power Rails) – 1 pc

• 140 pcs Breadboard Jumper Wire Kit – 1 set

🎯 Key Benefits

• ✅ Complete Learning Kit – All-in-one package for digital logic experiments.

• ✅ Ideal for Students – Supports coursework in Computer Science, Electrical, and Electronics Engineering.

• ✅ Hands-On Practice – Build real circuits like counters, registers, decoders, and timers.

• ✅ Reusable & Organized – Durable breadboard and jumper wires included for repeated experiments.

• ✅ Supports Lab Training – Perfect for classroom demonstrations and practical labs.

📌 Applications

The Digital Logic Circuits Lab Kit is perfect for:

• University and college digital electronics labs.

• Hands-on learning for logic circuits and sequential design.

• DIY electronics and Arduino prototyping.

• Practicing with timers, counters, shift registers, and display drivers.

• Strengthening foundations in digital system design.
