Description

The Alamein International University – Logic CS/CE Kit is a complete educational electronics package designed specifically for students studying Computer Science (CS) and Computer Engineering (CE) courses focused on Digital Logic Design. This kit provides everything needed to understand, build, and test fundamental logic circuits, counters, timers, and basic electronic systems.

Whether you’re working in a university lab, doing home experiments, or preparing for digital system design projects, this kit includes all essential components—from logic gates and resistors to breadboards and power modules—ensuring a comprehensive hands-on learning experience.

---

Key Features

• 🔹 Ideal for Logic Design and Digital Circuits Courses
  Tailored to meet the curriculum requirements of Alamein International University (AIU) Logic CS/CE programs.

• 🔹 All-in-One Learning Kit
  Includes breadboard, power module, ICs, resistors, LEDs, capacitors, and jumper wires—everything needed for digital electronics experiments.

• 🔹 Practical and Reusable Components
  High-quality, durable components allow repeated use in multiple lab exercises and projects.

• 🔹 Perfect for Prototyping and Circuit Testing
  The included MB102 Power Module and Breadboard make it easy to power and connect your circuits without soldering.

• 🔹 Comprehensive Component Range
  Covers the entire spectrum of logic circuits—from basic gates (AND, OR, NOT) to complex counters and display drivers.

---

Package Includes

1. Breadboard 840 Points (Splitted Power Rails) × 1

   • Large, high-quality board for easy circuit prototyping and testing.

2. MB102 Breadboard Power Supply Module (3.3V / 5V) × 1

   • Dual-voltage output for flexible power supply options.

3. Jumper Wires 20cm Male–Male × 40

   • Reusable connecting wires for clean, organized circuit layouts.

4. 5mm LED Lights – Round (All Colors) × 20

   • Visual indicators for logic state testing and signal outputs.

5. Resistors 330Ω 1/4W 5% × 20

   • Ideal for current limiting with LEDs and protecting ICs.

6. Resistors 1KΩ 1/4W 5% × 10

7. Resistors 10KΩ 1/4W 5% × 10

8. Resistors 22KΩ 1/4W 5% × 10

9. Resistors 100KΩ 1/4W 5% × 10

   • Standard resistor values for biasing, timing, and signal conditioning.

10. Potentiometer 500KΩ × 1

    • Adjustable resistance for variable input control and analog testing.

11. 7400 DIP Quad 2-Input NAND Gate × 3

12. 7402 DIP Quad 2-Input NOR Gate × 3

13. 7404 DIP Hex Inverter (NOT Gate) × 3

    • Core logic ICs used for creating combinational and sequential circuits.

14. 7448 DIP BCD to 7-Segment Decoder/Driver (with Internal Pull-ups) × 1

    • Converts binary-coded decimal inputs to drive a 7-segment display.

15. 7490 DIP Decade Counter (Divide-by-2 and Divide-by-5 Sections) × 1

    • For counting applications such as timers, digital clocks, and frequency dividers.

16. 7-Segment Display 0.56″ (Common Cathode, Red – 5161AS) × 1

    • Displays numerical output from counters or digital circuits.

17. NE555 / LM555 Timer IC – DIP-8 Precision Timer × 1

    • Versatile IC for generating clock pulses, delays, and PWM signals.

18. 10µF 25V Aluminum Electrolytic Capacitor × 2

19. 10µF 63V Aluminum Electrolytic Capacitor × 2

    • Used for timing circuits and power supply filtering.

---

Educational Value

This kit is designed to help students:

• Understand Boolean logic and logic gate operations.

• Build and analyze combinational and sequential circuits.

• Experiment with timers, counters, and display systems.

• Learn the basics of circuit design and troubleshooting.

---

Applications

• University lab experiments

• Logic circuit design and testing

• Digital electronics education

• Project-based learning and prototyping

---

Why Choose This Kit?

✅ Specially curated for AIU Logic CS/CE courses
✅ Includes over 20 essential components
✅ Beginner-friendly and reusable
✅ No soldering required — plug and play setup
✅ Ideal for both classroom and home lab use
