UNI-T UT385 Laser Power Meter
In Stock
Categories: UNI-T
Description
Key Features:
-
🔍 Wide Measurement Range: Accurately measures laser power from 0.01mW to 40.00mW, making it suitable for a broad range of laser sources.
-
💡 Wavelength Range: Supports a laser wavelength range from 400nm to 1100nm, covering the visible spectrum and near-infrared, ideal for common laser applications.
-
📊 High Accuracy: Provides reliable measurements with a high-resolution 0.01mW display and ±5% accuracy.
-
🔋 Auto Power-Off: The device automatically shuts off after a period of inactivity to conserve battery life.
-
🖥️ Clear LCD Display: Large, easy-to-read backlit LCD screen for working in various lighting conditions.
-
📏 Data Hold Function: Freeze the current reading on the screen for easy reference and recording.
-
🧳 Compact & Portable: Lightweight design with a protective rubber holster, making it easy to carry and durable for field use.
Technical Specifications:
| Specification | Details |
|---|---|
| Laser Power Range | 0.01mW to 40.00mW |
| Wavelength Range | 400nm – 1100nm |
| Accuracy | ±5% |
| Resolution | 0.01mW |
| Auto Power Off | Yes |
| Display | LCD with backlight |
| Power Supply | 9V battery (6F22) |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -10°C to 50°C |
| Dimensions | 170mm x 74mm x 30mm |
| Weight | Approx. 170g (including battery) |
Applications:
-
Laser diode testing
-
Fiber optic system maintenance
-
Medical laser equipment testing
-
Educational laboratory use
-
Industrial laser alignment and calibration
Package Includes:
-
UNI-T UT385 Laser Power Meter
-
Protective Holster
-
9V Battery
-
User Manual
Note: This device is not suitable for measuring high-power industrial lasers. Always follow laser safety guidelines when using laser equipment.
