UNI-T UT121A Smart Digital Multimeter

Key Features:

• True RMS Measurement: Ensures accurate readings for both sinusoidal and non-sinusoidal waveforms.

• Dual Display: Simultaneously shows two measurement results for enhanced convenience.

• Auto Range Function: Automatically selects the appropriate measurement range, simplifying operation.

• Non-Contact Voltage (NCV) Detection: Safely detects the presence of voltage without direct contact.

• Live Wire Detection: Identifies live wires to prevent electrical hazards.

• Continuity Buzzer: Provides audible alerts for continuity checks.

• High Voltage Alert: LCD display indicates high voltage conditions for user safety.

• Flashlight: Built-in flashlight for working in low-light environments.

• Low Battery Indication: Alerts when battery power is low.

• Auto Power Off: Conserves battery life by automatically turning off after a period of inactivity.

• Data Hold Function: Freezes the current measurement on the display for easy recording.

Specifications:

• AC Voltage Measurement: 6.000V/60.00V/600.0V ±(1.0%+3)

• AC Voltage Frequency Measurement: 10Hz–1kHz ±(0.5%+2)

• DC Voltage Measurement: 6.000V/60.00V/600.0V ±(0.7%+3)

• Resistance Measurement: 6000Ω/60.00KΩ/600.0KΩ/6.000MΩ/10.00MΩ ±(2.0%+5)

• Display Count: 6099

• Body Dimensions: 143mm × 74mm × 17mm

• Weight: Approximately 142g

• Power Supply: 2 × 1.5V AAA batteries

Applications:

• Electrical Troubleshooting: Identifying and diagnosing electrical issues in circuits.

• Routine Maintenance: Regular checks and maintenance of electrical systems.

• Educational Use: Teaching and learning about electrical measurements and safety.

• DIY Projects: Assisting in various home and hobbyist electrical projects.
