The MPU9250 GY-9250 Module is an advanced 9-Axis motion tracking sensor that integrates a 3-axis gyroscope, 3-axis accelerometer, and a 3-axis magnetometer. This module is designed for high-precision motion and orientation detection, making it a powerful tool for robotics, drones, and IoT projects.
Key Features:
9-Axis Sensor Integration: Combines gyroscope, accelerometer, and magnetometer in one compact module.
High Resolution: Features 16-bit ADC for precise measurement of motion and orientation.
Wide Measurement Range:
Gyroscope: ±250, ±500, ±1000, ±2000 degrees per second.
Accelerometer: ±2g, ±4g, ±8g, ±16g.
Magnetometer: ±4800μT.
I²C and SPI Interface: Supports multiple communication protocols for easy interfacing with microcontrollers.
Low Power Consumption: Optimized for battery-powered applications.
Compact Size: Small and lightweight, suitable for embedded systems.
Technical Specifications:
Power Supply Voltage: 2.4V to 3.6V
Communication Protocols: I²C (up to 400kHz) and SPI (up to 1MHz)
Output Resolution: 16-bit for all sensors
Operating Temperature: -40°C to +85°C
Dimensions: Compact PCB for easy integration
Applications:
Drones and UAVs: Enables stable flight by detecting orientation and motion.
Robotics: Provides accurate attitude control for navigation and movement.
Gaming and VR: Enhances user experience with precise motion tracking.
Wearables: Tracks movement and activity in fitness devices.
IoT Projects: Enables environment-aware systems for automation.
The MPU9250 GY-9250 offers unparalleled motion tracking capabilities, making it an essential component for advanced projects that require precise attitude and motion sensing.
