🔧 Key Features:

• Supports RS-485 and RS-422 standards

• Half-Duplex Communication

• Low Power Consumption

• Single +5V Supply

• Data Rates: Up to 2.5 Mbps

• Allows up to 32 transceivers on the bus

• Driver and Receiver Enable Pins for Bus Control

• Low-Cost, Industry-Standard DIP-8 Package

📦 Technical Specifications:

• Operating Voltage: +5V ±10%

• Receiver Input Resistance: ≥ 12kΩ

• Receiver Hysteresis: ~70 mV (typ.)

• Driver Output Voltage: ±5V (typ.)

• Operating Temperature Range: 0°C to +70°C (Commercial Grade)

• Package Type: DIP-8 (Also available in SOIC-8)

⚙️ Applications:

• Industrial RS-485 networks

• Building automation (HVAC, lighting control)

• Security and surveillance systems

• Factory automation and process control

• Data acquisition systems

• Multidrop serial communication setups

📝 Notes:

• Fully pin-compatible with industry-standard RS-485 transceivers.

• Built-in protection features include thermal shutdown and short-circuit protection.

• Ideal for use in power-sensitive or battery-powered applications.
