IRF9634 P-Channel Power MOSFET – TO-220
In Stock
Categories: Transistors
Overview
The IRF9634 is a high-voltage, medium-current P-Channel Power MOSFET designed for efficient switching and power management applications. It offers low on-resistance and fast switching speeds, making it ideal for power supplies, DC-DC converters, load switching, and amplification circuits. Packaged in the popular TO-220, it provides effective thermal dissipation and easy installation.
Description
✅ Key Features:
-
Drain-Source Voltage (Vds): -200V
-
Continuous Drain Current (Id): -9A @ 25°C
-
RDS(on): 0.22 Ohm (max)
-
Gate Threshold Voltage (Vgs(th)): -2.0 to -4.0V
-
Total Power Dissipation (Pd): 100W
-
Package Type: TO-220
-
Fast Switching Speed
-
Low Gate Drive Voltage
-
Robust and Durable Construction
🔧 Typical Applications:
-
Power supplies and converters
-
High-side load switching
-
DC-DC converters
-
Battery protection circuits
-
Audio amplifier output stages
-
General power switching and control
📦 Technical Specifications:
| Parameter | Value |
|---|---|
| Type | P-Channel MOSFET |
| Maximum Drain-Source Voltage (Vds) | -200V |
| Maximum Continuous Drain Current (Id) | -9A |
| Maximum RDS(on) | 0.22 Ohm |
| Gate Threshold Voltage (Vgs(th)) | -2.0 to -4.0V |
| Maximum Power Dissipation (Pd) | 100W |
| Package | TO-220 |
⚠️ Note:
Adequate heatsinking is recommended during high current operation to ensure reliable performance.
The IRF9634 is a versatile and reliable P-Channel MOSFET suitable for a wide range of power switching and management applications in industrial and hobbyist projects.
