IRF520 N-Channel Power MOSFET β TO-220
In Stock
Categories: Transistors
Description
β Key Features:
-
Drain-Source Voltage (Vds): 100V
-
Continuous Drain Current (Id): 9.2A @ 25Β°C
-
RDS(on): 0.27 Ohm (max)
-
Gate Threshold Voltage (Vgs(th)): 2.0 β 4.0V
-
Total Power Dissipation (Pd): 43W
-
Package Type: TO-220
-
Fast Switching Speed
-
Low Gate Drive Requirements
-
Good Thermal Stability
π§ Typical Applications:
-
Motor drivers and controllers
-
DC-DC converters and power supplies
-
Load switching circuits
-
Battery management systems
-
LED drivers
-
DIY electronics and robotics projects
π¦ Technical Specifications:
| Parameter | Value |
|---|---|
| Type | N-Channel MOSFET |
| Vds (Max) | 100V |
| Id (Max) | 9.2A |
| Rds(on) (Max) | 0.27 Ohm |
| Vgs(th) | 2.0 β 4.0V |
| Package | TO-220 |
| Power Dissipation (Max) | 43W |
β οΈ Note:
Proper heatsinking is advised to ensure safe operation under high load conditions.
The IRF520 offers a balance between performance and affordability, making it a popular choice for a wide range of power switching applications in both industrial and hobbyist environments.
