🔑 Key Features:

✔ JST XH Standard – 2.54mm pitch for compatibility with XH housings/cables ✔ 6-Pin Configuration – Ideal for multi-wire connections (e.g., RGBWW LEDs, sensor arrays, motor controls) ✔ Through-Hole PCB Mount – Robust solder joints for vibration resistance ✔ Gold-Plated Brass Contacts – Low resistance (≤15mΩ) and superior corrosion resistance ✔ High-Temp PA66 Housing (UL94 V-0) – Flame-retardant (-40°C to +125°C) ✔ Polarized Design – Keyed slot and alignment ribs prevent mis-mating

📌 Applications:

• Industrial Control Systems – PLC I/O interfaces

• LED Matrix Panels – High-density lighting control

• 3D Printer Mainboards – Multi-sensor/extruder wiring

• Drone Flight Controllers – Multi-channel signal transmission

• Test Equipment – Multi-probe measurement interfaces

📦 Package Options:

• Single unit

• Tape-and-reel packaging (1000pcs/reel)

• Complete kits with matching female crimp terminals

⚙ Technical Specifications:

🔧 PCB Design Guidelines:

1. Layout Recommendations:

   • Trace width: ≥0.5mm for 3A current

   • Clearance: 1.2mm between adjacent pins

2. Soldering Profile:

   • Lead-free: 260°C max (3 seconds contact)

   • Leaded: 240°C max (4 seconds contact)

Compliance: RoHS 3, REACH, UL certified

Keywords for SEO: *JST XH 6-pin header, 2.54mm high-density connector, industrial PCB terminal, gold-plated contact header*

For custom plating options (Au/Ni/Ag) or automated assembly services, contact our engineering team!
