ESP8266 ESP-12F Wifi Transceiver Wireless Module

Features/Specs:

• Compatibility: ESP-12
• Communication interface voltage: 3.3
• Working current: 240mA
• Serial port baud rate: 115200(can be modified)
• Serial communication format: 8N1
• Antenna Type: Built-in PCB antenna
• Wireless Network Mode: station/softAP/SoftAP station
• Wireless criteria: 802.11 b/g/n
• Compatible with ESP-12（ESP-202）
• WIFI @ 2.4 GHz, support for WPA / WPA2 security mode
• It is very easy to develop projects with AT commands
• Surface Mount Package with 2mm Pitch Pads
• Multiple GPIO’s for all your sensor needs
• Wi-Fi Direct (P2P), soft-AP
• Integrated TCP/IP protocol stack
• Integrated TR switch, balun, LNA, power amplifier, and matching network
• Integrated PLL, regulators, DCXO, and power management units
• 19.5dBm output power
• Power down leakage current of <10uA
• Integrated low power 32-bit CPU could be used as an application processor
• SDIO 1.1/2.0, SPI, UART
• STBC, 1×1 MIMO, 2×1 MIMO
• A-MPDU & A-MSDU aggregation & 0.4ms guard interval
• Wake up and transmit packets in < 2ms
• Standby power consumption of < 1.0mW (DTIM3)
• Both SMD and Inline packages are available, and the pin pitch is 2.0mm.
• Length: 16mm
• Width: 24mm
• Height: 4mm
• Weight: 2gm

Applications:

• Smart home
• Smart construction
• Industrial automation
• Portable devices
• IP camera
• Smart agriculture

Package included:

• 1 x ESP-12F ESP8266 Wi-Fi Wireless IoT Board Module.
