28BYJ-48 Stepper Motor 5V with ULN2003 Driver Module
Electra Store
SKU: MO-27073
70.00 EGP
In Stock
1
Categories: Generic
Description
Description
| Motor Type | Unipolar stepper motor. |
| Connection Type | 5 Wire Connection (to the motor controller). |
| Voltage | 5-12V DC. |
| Frequency | 100 Hz. |
| Step Mode | Half-step mode recommended (8 step control signal sequence). |
| Step Angle | Half-step mode: 8 step control signal sequence (recommended) 5.625 degrees per step / 64 steps per one revolution of the internal motor shaft. Full Step mode: 4 step control signal sequence 11.25 degrees per step / 32 steps per one revolution of the internal motor shaft. |
| Gear Ratio | Manufacturer specifies 64:1. |
| Wiring to The ULN2003 Controller | A (Blue), B (Pink), C (Yellow), D (Orange), E (Red, Mid-Point). |
| Weight | 44g. |
| Package Included | 1 x 28BYJ-48 Stepper Motor 5V. 1 x ULN2003 Driver Module. |
