Description

Core Specifications

• Power Capacity: 2000W continuous (2500W peak for 10ms)

• Voltage Range: 0-200V (±300V transient)

• Current Range: 0-60A (120A pulsed)

• Resolution: 0.01mV/0.01mA (18-bit ADC)

• Basic Accuracy: ±(0.02% of setting + 0.02% of range)

Advanced Operation Modes

Innovative Testing Capabilities

1. Smart Battery Emulation

   • Lithium/NiMH/Pb-acid profile libraries

   • 0.1% SOC precision for capacity testing

   • Battery aging simulation algorithms

2. Power Quality Analysis

   • 1MHz sampling rate for ripple analysis

   • 50th harmonic distortion measurement

   • Transient recovery time measurement

3. Automated Test Sequences

   • 200-step programmable sequences

   • Conditional branching logic

   • Multi-instrument synchronization

Technical Superiority

Measurement Performance

• Voltage Noise: <100μV RMS (20MHz BW)

• Current Stability: <50ppm/°C

• Dynamic Response: 5A/μs slew rate

• Minimum Pulse Width: 10μs

System Architecture

• Processor: Dual-core ARM Cortex-A72

• Memory: 4GB RAM + 64GB SSD

• Display: 8″ capacitive touchscreen (1920×1200)

• Cooling: Variable-speed vortex cooling system

Professional Connectivity

• Standard Interfaces:

  • USB 3.2 Gen 2 (10Gbps)

  • 10/100/1000BASE-T Ethernet

  • RS232/RS485 (isolated)

• Optional Interfaces:

  • GPIB (IEEE-488.2)

  • Optical USB for high-noise environments

  • CAN bus for automotive testing

Complete Package Contents

• Main unit with universal power cable

• Kelvin sense leads (10A rated)

• Optical isolation USB cable

• 2000W rated test leads

• NIST-traceable calibration certificate

• UTL-PRO software license

Industry-Leading Applications

• EV Battery Testing:

  • Charge/discharge cycle simulation

  • Battery management system validation

• Renewable Energy:

  • Solar panel IV curve tracing

  • Fuel cell impedance analysis

• Aerospace Power:

  • Satellite power system qualification

  • Aircraft electrical network simulation

• 5G Infrastructure:

  • Base station PSU stress testing

  • Edge computing power validation

Why Choose UTL8512+?

1. Unmatched Precision: 0.02% basic accuracy outperforms competitors

2. Future-Ready Platform: FPGA-based architecture for firmware upgrades

3. Intelligent Cooling: 50% quieter than comparable models

4. 5-Year Warranty: Industry-leading protection

Compliance: IEC 61010-1, ISO 17025, MIL-STD-810G
