Description

Key Features & Specifications

High-Performance Signal Generation:

• Dual 80MHz channels with 14-bit vertical resolution

• 500MSa/s sampling rate (1GSa/s in equivalent mode)

• 16kpts memory depth per channel (expandable via software)

• Ultra-low jitter: <500ps for precise timing applications

Versatile Waveform Capabilities:

• Standard waveforms: Sine, Square, Pulse, Ramp, Noise, DC

• 40+ built-in arbitrary waveforms (Sinc, Gaussian, ECG, etc.)

• User-defined arbitrary waveforms with easy PC software import

• Harmonic generation for complex signal simulation

Advanced Modulation & Control:

• Comprehensive modulation types: AM, FM, PM, FSK, ASK, PWM

• Linear/Logarithmic sweep with start/stop control

• Burst mode with programmable cycle counts

• External trigger input for system synchronization

User-Friendly Operation:

• 7-inch capacitive touchscreen with intuitive UI

• Quick-access function keys for efficient workflow

• Built-in help system with context-sensitive guidance

• Multiple display modes (XY, dual-view, etc.)

Connectivity & Expandability:

• USB Host & Device for storage and PC control

• LAN (LXI compliant) for remote operation

• Optional GPIB interface (module required)

• Sync output for multi-instrument setups

Measurement Quality:

• Low distortion: <0.3% THD (typical) @ 20MHz

• High amplitude accuracy: ±1% of setting

• Excellent frequency stability: ±1ppm

---

Typical Applications

• Circuit design and debugging

• Sensor simulation and testing

• Education and research experiments

• Power electronics development

• Automated test systems integration

• Communications system testing

---

Why Choose the UTG2082B?

✅ Dual-channel flexibility – Independent or synchronized operation
✅ Exceptional signal purity – Clean waveforms for accurate testing
✅ Touchscreen convenience – Faster setup and operation
✅ Future-ready connectivity – Ready for automated test environments
✅ Outstanding value – Professional features at competitive pricing

---

Package Includes

• UTG2082B Main Unit

• Power Cable

• USB Cable

• Quick Guide

• Certificate of Calibration

Upgrade your test bench today with UNI-T’s advanced waveform generation solution!
