Description

Key Advantages

▸ Metrology-Class Accuracy

• DC Voltage: ±(0.0035% of reading + 0.0005% of range)

• Resistance: ±0.005% with 0.1mΩ resolution

• Low Thermal EMF (<0.1μV) terminals

▸ Dual Measurement System

• Primary 6.5-digit display + secondary 4.5-digit display

• Simultaneous AC+DC or V+Hz measurements

▸ Advanced Connectivity

• Standard: USB-TMC, LAN (LXI Core), RS232

• Optional: GPIB (IEEE-488.2) for ATE systems

▸ Engineered for Stability

• 1ppm/°C voltage reference

• 24-hour ±15ppm accuracy

• 90-day calibration interval recommendation

Technical Specifications

Measurement Capabilities

Special Features

• Harmonic Analysis: Up to 50th order

• Data Logging: 500,000 point memory

• Math Functions: dB, dBm, relative, limit testing

• Auto-Calibration: Built-in self-check routines

Package Contents

• Main unit with IEC power cable

• UT-L20 precision test leads (1 pair)

• K-type thermocouple probe

• USB/RS232 interface cables

• NIST-traceable calibration certificate

Why Professionals Choose UT8802E

1. Cost-Performance Leader – Comparable to Keysight/Fluke at 40% lower cost

2. Future-Ready – Supports SCPI commands for test automation

3. Low Ownership Cost – Extended 3-year warranty available

Ideal Applications:
• Calibration laboratories (ISO 17025 compliant)
• Power electronics development
• Aerospace component testing
• Pharmaceutical equipment validation

Upgrade Options:

• GPIB interface module

• High-stability voltage reference option

• Rack mount kit
