UNI-T UT693D Optical Multimeter (Power Meter & VFL)
UNI-T UT693D Optical Multimeter (Power Meter & VFL)
UNI-T UT693D Optical Multimeter (Power Meter & VFL)
UNI-T UT693D Optical Multimeter (Power Meter & VFL)

UNI-T UT693D Optical Multimeter (Power Meter & VFL)

Original price was: 1,750.00 EGP.Current price is: 1,700.00 EGP.

The UNI-T UT693D Optical Multimeter is a high-performance, compact, and multifunctional fiber optic testing device that combines an optical power meter and visual fault locator (VFL) in a single tool. Designed for professionals working in fiber optic installation, maintenance, and troubleshooting, the UT693D ensures accurate, efficient, and convenient optical power measurements and fault detection.

SKU: UT693D Category:

Description

Key Features:

  • 🔹 2-in-1 Device: Combines an Optical Power Meter and Visual Fault Locator (VFL), reducing the need for multiple tools.

  • 🔹 Wavelength Range: Supports 800~1700 nm for power meter, compatible with single-mode and multi-mode fiber.

  • 🔹 VFL Output Power: Up to 10 mW VFL output for detecting breaks, bends, and faulty connectors up to 10 km.

  • 🔹 High Accuracy: ±5% measurement accuracy with linear and logarithmic display modes (dBm, mW, μW).

  • 🔹 Wavelength Identification: Pre-calibrated for 6 standard wavelengths (850/1300/1310/1490/1550/1625 nm).

  • 🔹 Large LCD Display: Backlit screen for easy reading in low-light environments.

  • 🔹 Auto Power-Off: Saves battery when idle.

  • 🔹 User-Friendly Interface: Simple buttons for switching modes, holding data, and selecting wavelengths.

  • 🔹 Durable Design: Compact and rugged build, suitable for fieldwork.

Specifications:

Parameter Details
Wavelength Range 800 ~ 1700 nm
Calibrated Wavelengths 850, 1300, 1310, 1490, 1550, 1625 nm
Power Measurement Range -70 ~ +10 dBm
Accuracy ±5%
Detector Type InGaAs
VFL Output Power 10 mW
VFL Wavelength 650 nm ±20 nm
VFL Range Up to 10 km
Display LCD with backlight
Connector Type FC/SC/ST (universal adapter included)
Battery 3 x 1.5V AA (not included)
Auto Power-Off Yes (configurable)
Dimensions 160 × 75 × 30 mm
Weight Approx. 200 g

Applications:

  • ✅ Optical fiber network installation and maintenance

  • ✅ FTTH (Fiber To The Home) and FTTx projects

  • ✅ Data center and telecom system troubleshooting

  • ✅ Field fiber optic testing and training

What’s in the Box:

  • UNI-T UT693D Optical Multimeter

  • Universal FC/SC/ST adapter

  • Protective carrying case

  • User manual

Why Choose the UNI-T UT693D?

Whether you’re a field technician or a network engineer, the UT693D is your reliable partner for fast and accurate fiber optic testing. With a compact design, dual functionality, and robust performance, it’s ideal for both daily maintenance tasks and advanced troubleshooting jobs.
