STC1000 Programmable Temperature Controller – All Purpose Digital Thermostat Temperature

Features:

• All-purpose temperature Controller STC-1000
• Mounting size: 71*29mm
• Auto switch between refrigerating and heating
• Return difference value
• Voltage:220 V AC±10%
• Front panel size 75(L) ×34.5(W) mm;
• Mounting size: 71(L) ×29(W) mm;
• Product size 75(L) ×34.5(W) ×85(D) mm;
• Sensor cable length:2m (include the probe).
• CE RoHS approval

Specification:

• Temperature measuring range: -50~99°C.
• Resolution: 0.1℃.
• Alarm temperature accuracy setting: 0.1℃
• Accuracy: ±1℃ (-50~70℃).
• Sensor error delay: 1 minute
• Power supply: 110V-220VAC±10%, 50/60Hz.
• Power consumption: ≤3W.
• Sensor: NTC sensor (1PC) cable 2 M, 10KΩ/25℃，B vale 3435K/(25℃～85℃).
• Relay contact capacity: Cool 10A/250VAC;Heat10A/250VAC.
• Ambient temperature: 0~60℃.
• Storage temperature: -30~75℃.
• Relative humidity: 20%~85% (No condensate).
