Slide Switch ON-OFF Panel Mount DPDT 6-Pin 2-Position 3A 250V

The Slide Switch ON-OFF Panel Mount DPDT 6-Pin 2-Position 3A 250V is a reliable and compact electromechanical switch designed for precise control of electrical circuits in electronic, industrial, and consumer applications. Featuring a Double Pole Double Throw (DPDT) configuration and a simple two-position ON-OFF sliding mechanism, this switch provides dependable circuit switching with excellent electrical isolation and long service life.

Designed for panel-mount installation, this slide switch is ideal for equipment where secure mounting, easy user access, and clear ON/OFF control are required. With a current rating of 3 amps at 250V AC, it is suitable for a wide range of low- to medium-power applications, including power control, signal routing, and mode selection.

---

DPDT Configuration for Versatile Circuit Control

This slide switch uses a DPDT (Double Pole Double Throw) design, meaning it can control two independent circuits simultaneously. Each pole can switch between two states, allowing greater flexibility compared to single-pole switches.

DPDT switches are commonly used in applications such as:

• Polarity reversal

• Signal switching

• Power routing

• Dual circuit isolation

• Mode or function selection

The 6-pin terminal layout provides clear and straightforward wiring, making integration into new designs or replacement of existing switches quick and efficient.

Learn more about DPDT switch configurations:
https://www.electronics-tutorials.ws/switches/dpdt-switch.html

---

Two-Position ON-OFF Sliding Mechanism

The 2-position ON-OFF design ensures simple and intuitive operation. The sliding actuator moves smoothly between positions, providing tactile feedback that confirms switching status. This makes it suitable for applications where clear visual and physical indication of circuit state is important.

Slide switches are often preferred over toggle switches in compact devices due to their low profile, precise control, and reduced accidental activation.

Overview of slide switch operation:
https://www.electronics-notes.com/articles/electronic_components/switches/slide-switch.php

---

Panel Mount Design for Secure Installation

This switch is designed for panel mounting, allowing it to be securely installed on metal or plastic enclosures. Panel mounting improves durability, user accessibility, and mechanical stability, especially in environments where switches are frequently operated.

The mounting structure ensures:

• Firm attachment to control panels

• Reduced strain on solder joints

• Professional and clean appearance

• Reliable long-term operation

This makes the switch ideal for control panels, instrumentation enclosures, test equipment, and DIY electronics projects.

---

Electrical Rating – 3A 250V AC

With a rating of 3A at 250V AC, this slide switch can safely handle common mains and control voltages used in electronics and electrical systems. This rating makes it suitable for both AC and low-voltage DC applications, depending on circuit requirements.

The internal contacts are manufactured from durable conductive materials designed to minimize contact resistance, reduce arcing, and ensure stable electrical performance over repeated switching cycles.

More on switch current and voltage ratings:
https://www.allaboutcircuits.com/textbook/direct-current/chpt-1/switches/

---

Durable Construction and Long Mechanical Life

The switch housing is made from high-quality insulating materials, providing excellent electrical insulation and resistance to heat and mechanical stress. Internal contact mechanisms are designed for long mechanical life, making the switch suitable for frequent operation.

Its compact yet rugged construction ensures consistent performance in both commercial and industrial environments.

---

Wide Range of Applications

The Slide Switch ON-OFF Panel Mount DPDT 6-Pin is widely used in:

• Electronic control panels

• Power supplies and adapters

• Audio and video equipment

• Test and measurement instruments

• DIY electronics and hobby projects

• Industrial control systems

• Automotive and marine electronics

• Educational and laboratory equipment

Its versatility and reliability make it a popular choice for both manufacturers and repair technicians.

---

Key Specifications Overview

• Product type: Slide switch

• Switching type: DPDT (Double Pole Double Throw)

• Positions: 2-position (ON-OFF)

• Number of pins: 6

• Mounting type: Panel mount

• Rated current: 3A

• Rated voltage: 250V AC

• Actuator type: Sliding lever

• Application: Power and signal switching

---

Why Choose This DPDT Slide Switch?

This panel mount slide switch offers an excellent balance of electrical performance, mechanical reliability, and installation convenience. Its DPDT configuration allows complex switching tasks in a compact form factor, while the ON-OFF operation ensures simple and safe control.

Whether used in professional equipment, industrial systems, or DIY electronics, this switch provides dependable performance and long-term durability.
