Description

🌟 Key Features

1. RP2040 Dual-Core Performance

• Dual ARM Cortex-M0+ @ 133MHz

• 264KB SRAM + 2MB Flash

• Programmable I/O (PIO) for custom peripherals

2. High-Quality 0.96″ IPS Display

• 128×64 resolution (sharp text and graphics)

• IPS technology (170° viewing angle)

• 65K colors (vibrant visuals)

• Built-in backlight (adjustable brightness)

3. Compact All-in-One Design

• Same footprint as Raspberry Pi Pico

• Onboard display eliminates wiring hassles

• Pre-soldered headers for easy prototyping

4. Expansion Capabilities

• 20x GPIO pins (including display interface)

• USB Type-C for power and programming

• I2C/SPI/UART interfaces available

---

🚀 Ideal Applications

✔ Embedded GUI projects (menus, dashboards)
✔ Portable gaming devices
✔ Sensor displays (weather stations, IoT)
✔ Educational tools (coding visualization)
✔ DIY wearables (compact display solution)

---

📊 Technical Specifications

---

🛠️ Development Support

• Compatible with:

  • MicroPython (with display drivers)

  • Arduino IDE (community-supported)

  • C/C++ SDK (official Raspberry Pi tools)

• Includes sample code for:

  • Graphics rendering

  • Text display

  • UI elements

---

📦 Package Contents

• 1× RP2040-LCD-0.96 Pico Board

• 1× USB Type-C Cable

• Quick Start Guide

Optional Accessories:

• Protective display cover

• GPIO expansion shield

• Battery connector kit

---

💰 Pricing & Availability

Standard Version: $14.90
Bulk Discounts: Available for orders >50 units

---

❓ Why Choose This Board?

✅ No display wiring needed – Fully integrated solution
✅ Vibrant IPS colors – Better than standard OLED
✅ Pico-compatible – Use existing RP2040 knowledge
✅ Beginner-friendly – Works with MicroPython
