- High quality immersion gold surface plating.
- Back light control to lower power consumption.
- You can use HDMI cable and MINI USB cable to connect with any version of Rasp pi.
- Driver is provided for the third generation Pi (works with custom Raspbian directly).
- HDMI interface for displaying, no I/Os required (however, the touch panel still needs I/Os).
- Not only the Pi, you can also use it with any other Mini-PCs like Cubieboard, Marsboard (resolution is limited depending on the board, and touch panel is unavailable).
- This LCD is also common HDMI display, even as a computer monitor 5 inch LCD HDMI Touch Screen Display Module for Rasp Pi.
- Resolution: 800*480
- Fit for: Raspberry Pi 2 3 Model B
How to Connect:
1. Connect this LCD to Rasp PI with HDMI cable.
2. Insert TF CARD with System image.
3. Connect Rasp pi to Power with micro usb cable.
4. Power on.
5. Wait some second,You will see the System is run!
Note: If you want to use this LCD as general monitor, the mini USB port is used for power supply
you just connect HDMI to any device(with LCD power by mini port)
1x HDMI Touch Screen
1x HDMI Adapter
1x Touch Pen
HDMI Touch Screen
